Power : 50W / 80W / 100W / 120W / 150W / 160W/ 200W / 250W / 240W / 300W
Lamp Color：Gray BlackColor Temperature: 3000K / 4000K / 5000K / 6000K
Light Source：LED
Add：Zhangting Industrial Park,Yuyao City,Zhejiang 315400
Power : 50W / 80W / 100W / 120W / 150W / 160W/ 200W / 250W / 240W / 300W
Lamp Color：Gray BlackColor Temperature: 3000K / 4000K / 5000K / 6000K
Light Source：LED
● The light body adopts the aluminum alloy withthe shot-blasting and high-pressure electrostatic plastic-sprayed surface, withhigh corrosion resistance.
● Polycarbonate transparent cover, Theprotection grade is IP66;
● Good heat dissipation effect by the airconvection;
● Eutectic welding without gold thread, toavoid the phenomenon of break and dead light.
● LED driver based on intelligent constantcurrent technique, prolonging the life;
● The light has been widely used in the roadand square etc.
Specification
Input Voltage：100～277V
Life Time：＞50000h
Protection Grade: ProtectionGrade: The whole light is IP68, the LED driver is IP67
Model | Nominal power | Luminous Efficacy(lm/W） | Total Luminous Flux (lm) | Power Factor | Color Temperature(K) | Color Rendering Index(Ra) | Temperature of Working Condition(℃） | Product Dimension（mm）
| Net Weight (kg) |
YC3302-1 | 50 | 110 | 5500 |
＞0.98 |
3000 4000 5000 6000 |
70±5 |
-40～+50 | 450×335×170 | 3.8 |
YC3302-2
| 80 | 115 | 9200 | 531×335×170 | 4.8 | ||||
100 | 110 | 11000 | |||||||
YC3302-3
| 120 | 115 | 13800 | 615×335×170 | 6 | ||||
150 | 110 | 16500 | |||||||
YC3302-4
| 160 | 115 | 18400 | 700×335×170 | 6.5 | ||||
200 | 110 | 22000 | |||||||
YC3302-5 | 200 | 115 | 230000 | 783×335×170 | 8 | ||||
250 | 110 | 27500 | |||||||
YC3302-6 | 240 | 115 | 27600 | 867×335×170 | 8.5 | ||||
300 | 110 | 33000 |
