Power : 60W / 80W / 100W / 120W / 150W / 180W / 200W / 240W / 300W
Lamp Color: Gray BlackColor Temperature: 3000K / 4000K / 5000K / 6000K
Light Source:LED
Add:Zhangting Industrial Park,Yuyao City,Zhejiang 315400Power : 60W / 80W / 100W / 120W / 150W / 180W / 200W / 240W / 300W
Lamp Color: Gray BlackColor Temperature: 3000K / 4000K / 5000K / 6000K
Light Source:LED
● Modular combination, easy to operate and maintain;
● The light body adopts the die casting aluminum alloy with the shot-blasting and high-pressure electrostatic plastic-sprayed surface, with high corrosion resistance.
● Polycarbonate transparent cover, double coupling protection, The protection grade IP68;
● Good heat dissipation effect by the air convection;
● Eutectic welding without gold thread, to avoid the phenomenon of break and dead light.
●Good color rendering index,no flicker,green and energy saving,and environmental protection.
● LED driver based on intelligent constant current technique, prolonging the life;
● The light has been widely used in the road and square etc.
Specification:
InputVoltage: 100~277V
Life Time: >50000h
Protection Grade: LEDModular Combination is IP68, the LED driver is IP67
Model | Nominal Power | Luminous Efficacy(lm/W
| Total Luminous Flux (lm) | Power Factor | Color Temperature(K)
| Color Rendering Index(Ra)
| Temperature of Woring Condition (℃) | Product Dimension(mm)
| Net Weight (kg) |
YC3301-2
| 60 | 120 | 7200 |
>0.98 |
3000 4000 5000 6000 |
70±5 |
-40~+50 |
650×370×130 |
6.5 |
80 | 115 | 9200 | |||||||
100 | 110 | 11000 | |||||||
YC3301-3
| 90 | 120 | 10800 |
730×370×130 |
8.0 | ||||
120 | 115 | 13800 | |||||||
150 | 110 | 16500 | |||||||
YC3301-4
| 120 160 200 | 120 115 110 | 14400 18400 22000 |
810×370×130 |
9.3 | ||||
YC3301-5
| 150 200 240 | 120 115 110 | 18000 23000 26400 |
890×370×130 |
10.5 | ||||
YC3301-6
| 180 240 300 | 120 115 110 | 21600 27600 33000 |
970×370×130 |
12 |
