Power : 26W / 30W / 35W / 40W / 50W / 60W / 75W / 90W / 100W
Lamp Color： Gray BlackColor Temperature: 3000K / 4000K / 5000K / 6000K
Light Source：LED
Add：Zhangting Industrial Park,Yuyao City,Zhejiang 315400
Power : 26W / 30W / 35W / 40W / 50W / 60W / 75W / 90W / 100W
Lamp Color： Gray BlackColor Temperature: 3000K / 4000K / 5000K / 6000K
Light Source：LED
● The lightbody adopts the aluminum alloy with the shot-blasting and high-pressureelectrostatic plastic-sprayed surface, with high corrosion resistance.
● Transparenttoughened glass cover, it also cloud be used by PC transparent cover, theprotection grade is IP66;
● Good heatdissipation effect by the back of the whole lamp;
● Eutecticwelding without gold thread, to avoid the phenomenon of break and dead light.
● LED driverbased on intelligent constant current technique, prolonging the life;
● The lighthas been widely used in the road and square etc.
Specification：
Input Voltage: 100～277V
Life Time: ＞50000h
Protection Grade: The whole light is IP68, the LED driver is IP67
Model Nominal power Luminous Efficacy(lm/w Total Luminous Flux (lm) Power Factor Color Temperature(K) Color Rendering Index(Ra) Temperature of Working Condition(℃） Product Dimension（mm） Net Weight (kg) YC3306-26 26 110 2860 ＞0.98 3000 4000 5000 6000 70±5 -40～+50 340×175×45 2 YC3306-30 30 110 3300 YC3306-35 35 110 3850 YC3306-40 40 110 4400 475×215×50 2.6 YC3306-50 50 110 5500 YC3306-60 60 110 6600 YC3306-75 75 110 7250 565×265×55 4.2 YC3306-90 90 110 9900 YC3306-100 100 110 11000
