Power : 60W / 80W / 100W / 120W / 150W / 200W / 240W / 300W
Lamp Color： Gray Black
Color Temperature: 3000K / 4000K / 5000K / 6000K
Add：Zhangting Industrial Park,Yuyao City,Zhejiang 315400
Power : 60W / 80W / 100W / 120W / 150W / 200W / 240W / 300W
Lamp Color： Gray Black
Color Temperature: 3000K / 4000K / 5000K / 6000K
● The lightbody are made of the aluminum alloy and are complete with oxdation treatment, with the high corrosion resistance.
● Polycarbonatetransparent cover, The protection grade is IP66;
● Good heatdissipation effect by the air convection;
● Eutecticwelding without gold thread, to avoid the phenomenon of break and dead light.
● LED driverbased on intelligent constant current technique, prolonging the life;
● The lighthas been widely used in the road and square etc.
Specification：
Input Voltage: 100～277V
Life Time: ＞50000h
Protection Grade: LED Modular Combination is IP68, the LED driver is IP67
Model Nominal Power Luminous Efficacy(lm/W) Total Luminous Flux (lm) Power Facto Color Temperature(K) Color Rendering Index(Ra) Temperature of Working Condition(℃） Product Dimension（mm） Net Weight (kg) YC3303-2 80 115 9200 ＞0.98 3000 4000 5000 6000 70±5 -40～+50 350×300×86 5.2 100 110 11000 YC3303-3 120 115 13800 440×300×86 5.5 150 110 16500 YC3303-4 160 115 18400 510×300×86 5.8 200 110 22000 YC3303-5 200 115 23000 600×300×86 6 250 110 27500 YC3303-6 240 115 27600 690×300×86 6.2 300 110 33000
